XFP Transceiver Modules for 8G/16G Fibre Channel, 10GbE, SONET/SDH & OTN

This portfolio of XFP pluggable optical transceiver modules supports a comprehensive range of data rates, including 8G/10G/16G Fibre Channel, 10G Ethernet, SONET OC-192, SDH STM-64, and OTN OTU2e.

Available variants cover diverse reach requirements:

• SR: up to 400m

• LR: up to 10km

• ER: up to 40km

• ZR: up to 80km

• BiDi: 10km to 80km

• CWDM: 10km to 80km

• DWDM: 40km to 80km

• Tunable DWDM: up to 80km



  SFP+/SFP Transceiver Product Summary

  Product Description	Data Rate	Wavelength	Distance	Max. Power Dissipation	Temperature Grade	Part Number(s)
  8G SFP+ SR	8.5 Gbps	850 nm	400 m	1 W	C / I	VPP-858G-SRC, GPP-858G-SRT
  8G SFP+	8.5 Gbps	1310 nm	2 km	1 W	C / I	VPP-318G-02C
  8G SFP+ LR	8.5 Gbps	1310 nm	10 km	1 W	C / I	VPP-318G-LRC, GPP-318G-LRT
  8G SFP+ ER	8.5 Gbps	1550 nm	40 km	1 W	C / I	VPP-558G-ERC
  8G SFP+ ZR	8.5 Gbps	1550 nm	80 km	1 W	C / I	VPP-558G-ZRC
  10G SFP+ SR	10.3125 Gbps	850 nm	300m (OM3), 400m (OM4)	0.8 W	C / I	VPP-85192-SRC, GPP-85192-SRT
  10G SFP+ LR	10.3125 Gbps	1310 nm	10 km	1 W	C / I	VPP-31192-LRC, GPP-31192-LRT, GPP-31192-LRCS
  10G SFP+ CWDM	10.5/10.7/11.3 Gbps	CWDM	10 – 80 km	1.8 W	C / I / E	VCP-XX192-01T
  10G SFP+ DWDM	10.3125/11.3 Gbps	DWDM	40km / 70km / 80km	1.5W / 2W	C / I / E	VDP-XXX192-08C
  16G SFP+ SR	14.025 Gbps	850 nm	100m (OM3), 190m (OM4)	1 W	C / I	VPP-8514G-SRC
  16G SFP+ LR	14.025 Gbps	1310 nm	10 km	1 W	C / I	VPP-3114G-LRC
  16G SFP+ ER	14.025 Gbps	1310 nm	40 km	1 W
  16GFC SFP+ CWDM	14.025 Gbps	CWDM	40 km	1.8 W	C	VCP-xx14G-04C
  16GFC SFP+ DWDM	14.025 Gbps	DWDM	10 km	1.8 W	C / I	VDP-Dxx14G-04x
  16GFC SFP+ DWDM	14.025 Gbps	DWDM	40 km	1.8 W	C / I	VDP-Dxx14G-04x
