S6730-S24X6Q 24-Port 10GbE SFP+ SNMP Switch for High-Density Networks

No.S6730-S24X6Q

Port Configuration:

  • Downlink Ports: 24 x 10 Gigabit SFP+

  • Uplink Ports: 6 x 40/100 Gigabit QSFP28

  • Fixed Ports: Yes

Performance:

  • Switching Capacity: 960 Gbps / 2.4 Tbps

  • Forwarding Performance: 490 Mpps

  • Chassis Height: 1U

Key Features:

  • Stackable

  • VLAN Support

  • Link Aggregation Control Protocol (LACP)

  • SNMP Management

  • Full-Duplex & Half-Duplex Communication

  • VXLAN-based Virtualization

  • S6730-S24X6Q 24-портовый 10GbE SFP+ SNMP-коммутатор для сетей высокой плотности
  • S6730-S24X6Q 24-Port 10GbE SFP+ SNMP Switch for High-Density Networks
  • S6730-S24X6Q 24-Port 10GbE SFP+ SNMP Switch for High-Density Networks
  • S6730-S24X6Q 24-Port 10GbE SFP+ SNMP Switch for High-Density Networks
  • Description
  • Additional Information
  • Ordering & Payment Terms

Product Overview: CloudEngine S6730-S24X6Q Switch

The CloudEngine S6730-S24X6Q is a high-performance 10 Gigabit Ethernet switch designed for enterprise campuses, data centers, and other high-traffic environments. It combines high-density 10G access with high-speed 40/100G uplinks in a compact 1U form factor, supporting advanced features for modern, converged networks.

Detailed Feature Highlights

1. High-Speed Connectivity & Performance
This switch delivers robust performance with 24x 10GE SFP+ ports for server and user access, and 6x 40/100GE QSFP28 ports for high-bandwidth uplinks. With a switching capacity of up to 2.4 Tbit/s, it ensures non-blocking performance for demanding applications.

2. Wired and Wireless Convergence
As part of the CloudEngine S6730 Series, this model integrates native WLAN Access Controller (AC) capabilities, supporting the management of up to 1024 Access Points (APs). This enables seamless convergence of wired and wireless networks, simplifying operations and delivering a consistent user experience.

3. Advanced Network Virtualization
The switch supports VXLAN (Virtual Extensible LAN) technology, creating a flexible, multi-purpose network overlay that is ideal for multi-tenancy and network segmentation.

4. Enhanced Security
The series is equipped with built-in security features, including security probes for abnormal traffic detection and Encrypted Communications Analytics (ECA), providing enhanced threat visibility and network-wide protection.

5. Target Applications
Ideal for a wide range of scenarios, including:

  • Enterprise Campuses

  • Carrier Networks

  • Higher Education Institutions

  • Government Networks

S6730-S24X6Q: 24-Port 10GbE SFP+ SNMP Switch for High-Density Networks

  • Breakdown: Leads with the model number, clearly states the port count and type, and highlights the key features (SNMP) and use case.

    Product Model
    CloudEngine S6730-H48X6C
    CloudEngine S6730-H24X6C
    CloudEngine S6730-H24X4Y4C
    Switching Capacity2
    2.16/2.4 Tbit/s
    1.68/2.4 Tbit/s
    1.48Tbps/2.4Tbps
    Fixed Ports
    48 x 10 GE SFP+, 6 x 40/100 GE QSFP28
    24 x 10 GE SFP+, 6 x 40/100 GE downlink QSFP28
    24 x 10 Gig SFP+, 4 x 25 Gig SFP28, 4 x 100 Gig QSFP28
    Wireless Services
    Management of up to 1024 APs
    AP access control, AP domain management, and AP configuration template management
    Radio channel management, unified static configuration, and dynamic centralized management
    WLAN basic services, QoS, security, and user management
    CAPWAP, tag/terminal location, and spectrum analysis
    iPCA
    Collection of real-time statistics on the number of lost packets and packet loss ratio at network and device levels
    Super Virtual Fabric (SVF)
    Functions as the parent node to virtualize downstream switches and APs vertically as one device for simpler management
    Supports a two-layer client architecture
    Supports third-party devices between SVF parent and clients
    VXLAN
    VXLAN L2 and L3 gateways
    Centralized and distributed gateways
    BGP-EVPN
    Configured through the NETCONF protocol
    Interoperability
    VBST (compatible with PVST, PVST+, and RPVST)
    LNP (similar to DTP)
    VCMP (similar to VTP)

Ordering & Payment Terms:

  • Minimum Order Quantity (MOQ): Flexible for small orders
  • Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
  • Payment Method: T/T (Bank Transfer)
  • Payment Terms:
    30% advance payment, with 70% balance due prior to shipment for bulk orders


BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
