Product Overview
The VQS-MPO201-SR2C is a hot-pluggable QSFP56 parallel fiber optic transceiver designed for high-performance 200 Gigabit Ethernet applications. It is engineered for short-range multi-lane data communication and interconnect solutions in data centers and high-performance computing environments.
Key Features
Form Factor: QSFP56 (Pluggable)
Data Rate: 200 Gbps aggregate
Reach: Up to 60 m on OM3 multimode fiber or 100 m on OM4 multimode fiber (with FEC)
Wavelength: 850 nm
Optical Connector: 12-fiber MTP/MPO
Management: Compliant with the Common Management Interface Specification (CMIS)
Technical Specifications
| Parameter | Specification |
|---|---|
| Form Factor | QSFP56 |
| Host Interface | 4 electrical lanes @ 53.125 Gbit/s (PAM4) |
| Aggregate Data Rate | 200 GbE |
| Operating Wavelength | 850 nm |
| Optical Interface | 2 parallel optical lanes @ 106.25 Gbit/s (PAM4) |
| Max Distance | 60 m (OM3), 100 m (OM4) |
| Fiber Type | Multimode (MMF) |
| Connector | 12-fiber MTP/MPO |
| Digital Diagnostics | CMIS (Common Management Interface Specification) |
Functional Description
The GQS-MPO201-SR2C performs a 4:2 electrical-to-optical (EO) and optical-to-electrical (OE) conversion:
Transmit Direction: Converts four input electrical lanes (53.125 Gbit/s each) into two parallel optical lanes, each transmitting at 106.25 Gbit/s.
Receive Direction: Converts two parallel optical input lanes (106.25 Gbit/s each) back into four output electrical lanes.
Technology & Reliability
This module leverages Gigalight's proven circuit and VCSEL (Vertical-Cavity Surface-Emitting Laser) technology to ensure high reliability, long service life, and consistent performance.
Part Number: VQS-MPO201-SR2C
Product Specifications: 200G QSFP56 Optical Transceiver
Product Type: Pluggable Optical Module
Form Factor: QSFP56
Application: Data Center Interconnect
Performance & Capabilities
Data Rate: 200 Gbps
Supported Protocols: Ethernet, InfiniBand
Transmission Reach: 0.5 meters to 2 kilometers
Optical Characteristics
Media Type: Multimode Fiber (MMF)
Wavelength: 850 nm
Interface / Connector: MPO/MTP
