QSFP28 100G-SR4 Optical Transceiver Module VCSEL 850nm 100m

The 100G QSFP28 SR4 transceiver is engineered for high-speed, short-reach links within data centers.

• Application: Short-range interconnections between devices in data centers.

• Compliance: IEEE 802.3bm 100GBASE-SR4 Ethernet.

• Multi-rate Compatibility: Optional versions support 100G Ethernet, OTN OTU4, and 128GFC.

• Technology: Uses 4 parallel lanes over multimode fiber (MMF) with a 850nm center wavelength.

• Reach: Supports distances up to 70m on OM3 and 100m on OM4 fiber.

• Operating Temp: Available with an optional industrial-grade temperature range.



  Part Number	Description
  VQS-MPO101-SR4C	100GE QSFP28 SR4 Optical Module, VCSEL 850nm, 100m Reach
  VQS-MPO101-SR4T	Industrial-grade 100GE/CPRI QSFP28 SR4 Optical Module, VCSEL 850nm, 100m Reach
  VQS-MPO111-SR4C	100GE/OTU4/128GFC QSFP28 SR4 Optical Module, VCSEL 850nm, 100m Reach
  VQS-MPO111-SR4T	Industrial-grade 100GE/OTU4/128GFC QSFP28 SR4 Optical Module, VCSEL 850nm, 100m Reach

  Product Specifications: QSFP28 Optical Transceiver

  • Product Type: Pluggable Optical Module

  • Form Factor: QSFP28

  • Data Rate: 100G-112G

  Key Features

  • Application: 5G Carrier Network, Data Center, Metropolitan Area Network, Telecom

  • Protocol: CPRI / eCPRI, Ethernet, Fibre Channel, InfiniBand, OTN

  • Media Type: Multi-Mode Fiber (MMF)

  • Wavelength: 850nm

  • Reach: 0.5m to 2km

  • Interface: MPO/MTP
