QSFP28 100G LR4 Optical Transceiver | LWDM4 DML | 10km/20km Reach

The 100G QSFP28 LR4 optical module is designed for long-distance data transmission.

• Application: Datacom and Telecom

• Standard: Compliant with IEEE 802.3ba 100GBASE-LR4.

• Capability: Optional dual-rate versions support 100G Ethernet and OTN OTU4.

• Technology: Integrated 4-channel LWDM MUX and DEMUX.

• Wavelengths: 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm.

• Media: Single-mode fiber pair.

• Reach: Up to 10km or 20km (without FEC).



  Part Number	Description
  VQS-SPO101-LR4C	100GE QSFP28 LR4 DML LWDM4 10km Optical Transceiver Module
  VQS-SPO101-LR4T	Industrial Grade 100GE QSFP28 LR4 DML LWDM4 10km Optical Transceiver Module
  VQS-SPO111-LR4C	100GE/OTU4 QSFP28 LR4 DML LWDM4 10km Optical Transceiver Module
  VQS-SPO111-L24C	100GE/OTU4 QSFP28 LR4 DML LWDM4 20km Optical Transceiver Module
  VQSR-SPO101-LR4C	100GE QSFP28 LR4 DML LWDM4 10km Optical Receiver Module


• Product Specifications

  • Product Type: Pluggable Optical Transceiver

  • Form Factor: QSFP28

  • Media Type: Single-Mode Fiber (SMF)

  • Interface: Dual LC

  Performance Specifications

  • Data Rate: 100G to 112G

  • Wavelength: LAN-WDM

  • Reach: 2 km to 20 km

  Application & Protocol

  • Protocols: Ethernet, OTN (Optical Transport Network)

  • Applications:

    • 5G Carrier Network

    • Data Center Interconnect (DCI)

    • Metropolitan Area Network (MAN)

    • Telecom Transport
