QSFP28 100G ER4 Lite Optical Transceiver 30km/40km DML LWDM4

The 100G QSFP28 ER4 optical transceiver module is designed for long-distance transmission in both data communication and telecommunications applications. It complies with the 100G Ethernet standard and is also compatible with the OTN OTU4 protocol.

The module incorporates an integrated 4-channel LWDM MUX and DEMUX, with center wavelengths at 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm. It supports transmission over a single-mode fiber pair, achieving distances of up to 30 km without Forward Error Correction (FEC) and up to 40 km with FEC.

Product Specifications: QSFP28 100G ER4 Lite Optical Transceiver

• Product Type: Pluggable Optical Module

• Form Factor: QSFP28

• Data Rate: 100G

• Wavelength: LAN-WDM

• Media Type: Single-Mode Fiber (SMF)

• Reach: 25km - 50km

• Interface: Dual LC

Applications:

• Data Center Interconnects (DCI)

• 5G Carrier Network

• Metropolitan Area Network (MAN)

• Telecom Transport

Supported Protocols:

• Ethernet

• Fibre Channel

• InfiniBand

• OTN (Optical Transport Network)

Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders

BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
