H3C UniServer R6900 G3 Rack Server

No.UniServer R6900 G3
  • Product Name: H3C UniServer R6900 G3 Rack Server

  • Form Factor: 4U

  • Processors: 4 x Intel Xeon 5218 (or 4 x Intel Xeon 5218 CPUs)

  • Memory: 8 x 32GB DDR4 RDIMMs (256GB Total)

  • Storage Controller: H3C P460 RAID Card

  • Storage Drives: 3 x 1.2TB SAS/SATA HDDs

  • Power Supply: 4 x 800W Hot-Plug Redundant PSUs

  • H3C UniServer R6900 G3 Rack Server
  • H3C UniServer R6900 G3 Rack Server
  • H3C UniServer R6900 G3 Rack Server
  • Description
  • Additional Information
  • Ordering & Payment Terms

H3C UniServer R6900 G3 Rack Server - Product Overview

The H3C UniServer R6900 G3 is a high-performance 4-socket rack server designed for mission-critical applications. Built with the latest Intel® Xeon® Scalable processors and advanced DDR4 memory, it delivers exceptional performance, extensive expandability, and high energy efficiency. Its modular design is ideal for virtualization, big data, database processing, high-performance computing, and enterprise resource planning.

Detailed Specifications

Category Specification
Processor (Computing) Up to 4 x Intel® Xeon® Scalable Processors (Platinum/Gold Family), 4 to 28 cores, with a maximum TDP support of 205W.
Memory Up to 48 x DDR4 DIMM slots, supporting 2666MT/s, RDIMM, or LRDIMM. Maximum supported capacity of 6TB.
Storage Controllers: Standard SATA RAID 0/1/10/5. Optional SAS/SATA/NVMe HBA and Smart Array cards supporting RAID 0/1/10/5/6/50/60.
FBWC: Up to 2GB.
Drive Bays: Maximum of 48 x SFF front-mounted SAS/SATA drives or 16 x NVMe SSDs. Supports PCIe M.2.
Expansion Slots Up to 20 x PCIe 3.0 slots (18 rear, 2 front).
GPU Support Supports 2 x double-wide GPUs (up to 10.5”).
Networking Embedded: 1 x 1Gbps HDM management port.
Optional: 4 x 1GE, 2 x 10GE electrical, or 2 x 10GE optical ports via mLOM. Standard PCIe network adapters are also supported.
Ports Front (Optional): 1 x VGA, 2 x USB 2.0.
Rear (Standard): 1 x VGA, 1 x Serial, 2 x USB 3.0.
Internal: 1 x USB 3.0.
Management HDM agentless management tool (with dedicated port) and H3C FIST management software.
Power Supply Options: 800W / 1200W / 1600W (Platinum) or 800W 336VHDC.
Features: N+N Redundant, hot-swappable. 80 Plus Platinum certified with up to 96% energy efficiency.
Cooling Hot-swappable redundant fans.
Physical Dimensions 4U; 174.8mm (H) x 444mm (W) x 807.4mm (D) (without safety panel).
Operating Temperature 5°C to 45°C.
Certifications CCC, CECP, SEPA.
Warranty 3-year

Key Features & Supported Workloads

  • High Performance: Delivers up to 50% higher performance with Intel Xeon Scalable processors and 2666MT/s DDR4 memory.

  • Massive Expandability: Features up to 20 PCIe 3.0 slots for extensive I/O flexibility.

  • High Availability: Designed with reliability and availability for mission-critical operations.

  • Energy Efficient: Achieves up to 96% power supply efficiency.

  • Flexible Storage: Modular design supports a high density of SFF drives or high-speed NVMe SSDs.
