H3C S6520X-26C-SI 24-Port Gigabit/10G SFP+ L3 Switch

No.S6520X-26C-SI

H3C S6520X-26C-SI Layer 3 Ethernet Switch with 24 x 1G/10G SFP+ Ports and 1 Expansion Slot

Model: H3C S6520X-26C-SI
Ports: 24 x 1GbE/10GbE SFP+
Expansion: 1 Slot
Layer: 3
Type: Ethernet Switch

Available Models in the Series:
- S6520X-10XT-SI: 8 x 1G/2.5G/5G/10G Base-T Ports, 2 x 1G/10G SFP+ Ports
- S6520X-16XT-SI: 14 x 1G/2.5G/5G/10G Base-T Ports, 2 x 1G/10G SFP+ Ports
- S6520X-16ST-SI: 16 x 1/10G SFP+ ports (with 2 Combo Multi-giga Base-T ports), 2 power module slots
- S6520X-18C-SI: 16 x 1/10G SFP+ ports, 1 expansion slot, 2 power module slots
- S6520X-24ST-SI: 24 x 1/10G SFP+ ports (with 2 Combo Multi-giga Base-T ports), 2 power module slots
- S6520X-26C-SI: 24 x 1/10G SFP+ ports, 1 expansion slot, 2 power module slots
- S6520X-26MC-SI: 24 x 1G/2.5G/5G Base-T ports, 1 expansion slot, 2 power module slots
- S6520X-26MC-UPWR-SI: 24 x 100M/1G/2.5G/5G Base-T (UPOE) ports, 1 expansion slot, 2 power module slots
- S6520X-26XC-UPWR-SI: 24 x 100M/1G/2.5G/5G/10G Base-T UPoE ports, 1 expansion slot, 2 power module slots
- S6520X-54XC-UPWR-SI: 48 x 100M/1G/2.5G/5G/10G Base-T UPoE Ports, 4 x QSFP+ Ports, 1 expansion slot, 2 power module slots

Get The Latest Quote

Add to Quote List Browse the list

Description
Additional Information
Ordering & Payment Terms

The H3C S6520X-SI Switch Series is an industry-leading, high-performance, and scalable 10 Gigabit Ethernet access switching solution. Key features include modular dual power supplies for redundancy, fixed or modular uplinks (10GbE/40GbE), and IRF stacking for network resiliency. The series supports advanced routing protocols like OSPF and BGP, multicast, is SDN-enabled, and offers flexible management options.

Physical & Hardware Specifications

Fixed Ports: 24 x 1/10G SFP+
Expansion Slot: 1 slot for flexible uplinks
Power Supply: Built-in AC Power Supply
PoE Support: Not Supported
Switch Capacity: 336 Gbps
Forwarding Performance: 48 Mpps
Dimensions: 440 (W) x 360 (D) x 43.6 (H) mm
Weight: < 7 kg

Software & Management Features

Stacking: Supported (IRF Technology)
VLAN: VLAN Support
Link Aggregation: LACP (Link Aggregation Control Protocol)
Communication Mode: Full-Duplex & Half-Duplex
Transmission Rate: 10/100/1000Mbps (on management port) *

Item	S6520X-18C-SI	S6520X-26C-SI	S6520X-26MC-UPWR-SI S6520X-26MC-SI	S6520X-16ST-SI	S6520X-24ST-SI
Port switching capacity	480Gbps	720Gbps	400Gbps	320Gbps	480Gbps
Box switching capacity	2.56Tbps
Packet forwarding rate	357Mpps	536Mpps	240Mpps	240Mpps	357Mpps
Dimensions (W × D × H)	44036043.6	44036043.6	44046043.6	44036043.6	44036043.6
Weight	≤ 7 kg	≤ 7 kg	≤ 7 kg ≤6.4kg (UPWR)	≤ 7 kg	≤ 7 kg
Service ports	16 × 1/10GE SFP+ fiber ports	24 × 1/10GE SFP+ fiber ports	S6520X-26MC-UPWR-SI:24 × 100M/1G/2.5G/5GBase-T(UPOE) S6520X-26MC-SI: 24 ×100M/1G/2.5G/5GBase-T	16 × 1/10G SFP+ ports (2 Combo 1G/2.5G/5G/10G Base-T Multi-giga ports)	24 × 1/10G SFP+ ports (2 Combo 1G/2.5G/5G/10G Base-T Multi-giga ports)
Maximum stacking num	9
Routing number	IPv4 routing number 16K IPv6 routing number 8K
Stacking bandwidth	160Gbps
Routing number	IPv4 routing number 16KIPv6 routing number 8K
