200G QSFP-DD Direct Attach Copper Cables for Ethernet and InfiniBand EDR

No.200G QSFP-DD DAC
  • Hot-pluggable QSFP-DD direct attach copper cable assemblies
  • 8x 25G NRZ electrical interface
  • Data rate up to 25.78125Gbps per channel
  • Compliant with QSFP-DD MSA, CMIS and IEEE 802.3
  • Low power dissipation
  • Commercial case operating temperature range
  • Single 3.3V power supply
  • Built-in digital diagnostic functionality
  • RoHS compliant (lead free)
  • 200G QSFP-DD Direct Attach Copper Cables for Ethernet and InfiniBand EDR
  • Description
  • Ordering & Payment Terms
200G QSFP-DD Direct Attach Copper (DAC) cables support both 200 Gigabit Ethernet and InfiniBand EDR data rates.
  • Product Type: Direct Attach Copper (DAC) Cable

  • Form Factor: QSFP-DD

  • Data Rate: 200 Gbps

  • Application: Data Center

  • Protocol: Ethernet, InfiniBand

    Description Data Rate Distance Part Number
    200G QSFP28-DD PCC 206.25 Gbps 3m (30AWG) / 5m (26AWG) VQD-PC201-XXC
    200G QSFP28-DD to 2x 100G QSFP28 PCC 206.25 Gbps 3m (30AWG) / 5m (26AWG) VQD-2Q28P201-XXC

Ordering & Payment Terms:

  • Minimum Order Quantity (MOQ): Flexible for small orders
  • Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
  • Payment Method: T/T (Bank Transfer)
  • Payment Terms:
    30% advance payment, with 70% balance due prior to shipment for bulk orders
