3G to 10G CPRI SFP Optical Transceivers Supporting Options 4, 5, 6, 7, and 8

This series of 3G to 10G CPRI SFP pluggable optical transceiver modules supports CPRI data rates for Options 4, 5, 6, 7, and 8. The comprehensive portfolio features a variety of types to suit different application needs, including:

• LR: For distances up to 10 km.

• ER: For extended reaches up to 40 km.

• BiDi: Utilizing single-fiber bidirectional technology for distances ranging from 10 km to 80 km.

• CWDM: Coarse Wavelength Division Multiplexing versions for 10 km to 80 km.

• DWDM: Dense Wavelength Division Multiplexing versions for long-haul transmissions from 40 km to 80 km.



  CPRI Optical Transceiver Product List

  Product Type	Data Rate	Wavelength	Distance	Interface	Max Power	Operating Temp.	Product Number(s)
  3G/4.9G CPRI SFP	4.9152 Gbps	1310nm	10 km	Duplex LC	0.8 W	I	VP-315G-L1TI
  	4.9152 Gbps	1310nm	20 km	Duplex LC	0.8 W	I	VP-315G-L2TI
  	4.9152 Gbps	1310nm	40 km	Duplex LC	0.9 W	I	VP-315G-L4TI
  3G/4.9G CPRI SFP BiDi	4.9152 Gbps	1310nm/1550nm	10 km	Simplex LC	1.5 W	I	VBP-31555G-L1TI VBP-55315G-L1TI
  	4.9152 Gbps	1310nm/1550nm	20 km	Simplex LC	1.4 W	I	VBP-31555G-L2TI VBP-55315G-L2TI
  	4.9152 Gbps	1310nm/1550nm	40 km	Simplex LC	1.4 W	I	VBP-31555G-L4TI VBP-55315G-L4TI
  	4.9152 Gbps	1310nm/1550nm	80 km	Simplex LC	1.6 W	I	VBP-31555G-L8TI VBP-55315G-L8TI
  6G/10G CPRI SFP+	10Gbps/11.3Gbps	1310nm	2 km	Duplex LC	0.9 W	I	VPP-31192-02TI
  	10Gbps/11.3Gbps	1310nm	10 km	Duplex LC	1.1 W	I	VPP-31192-L1TI
  	10Gbps/11.3Gbps	1310nm	20 km	Duplex LC	1.1 W	I	VPP-31192-L2TI
  	10Gbps/11.3Gbps	1310nm	40 km	Duplex LC	1.4 W	I	VPP-31192-L4TI
  	10Gbps/11.3Gbps	1550nm	80 km	Duplex LC	2.0 W	I	VPP-55192-ZRT
  6G/10G CPRI BiDi SFP+	10.3 Gbps	1270nm/1330nm	10 km	Simplex LC	1.1 W	I	VBP-xxxx192-LRTI
  	10.3 Gbps	1270nm/1330nm	20 km	Simplex LC	1.1 W	I	VBP-xxxx192-L2TI
  	10.3 Gbps	1270nm/1330nm	40 km	Simplex LC	1.0 W	I	VBP-xxxx192-ERTI VBP-xxxx8G-ERTI
  	10.3 Gbps	1270nm/1330nm	60 km	Simplex LC	1.0 W	I	VBP-xxxx192-E6TI VBP-xxxx8G-E6TI
  	10.3 Gbps	1490nm/1550nm	80 km	Simplex LC	1.8 W	C/I	VBP-xxxx192-E8C
  6G/10G CPRI CWDM SFP+	10.3 Gbps	1271-1611nm	10 km	Duplex LC	1.5 W	C/I	VCP-xx192-01C VCP-xxx192-01T
  	10.3 Gbps	1271-1611nm	40 km	Duplex LC	1.8 W	C/I	VCP-xxx192-04C VCP-xxx192-04T
  	10.3 Gbps	1591-1661nm	70 km	Duplex LC	2.0 W	C/I	VCP-xxx192-07C VCP-xxx192-07T
  	10.3 Gbps	1471-1571nm	80 km	Duplex LC	2.0 W	C/I	VCP-xxx192-08C VCP-xxx192-08T
  6G/10G CPRI DWDM SFP+	10.3Gbps/11.3Gbps	C18-C61 (100GHz)	40 km	Duplex LC	2.0 W	C/I	VDP-xxx192-04T
  	10.3Gbps/11.3Gbps	C18-C61 (100GHz)	70 km	Duplex LC	2.0 W	C/I	VDP-xxx192-07T
  	10.3Gbps/11.3Gbps	C18-C61 (100GHz)	80 km	Duplex LC	1.8 W	C/I	VDP-xxx192-08C

Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders

BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
