100G QSFP28 PSM4 1310nm DML 2km/10km Optical Transceiver

The 100G QSFP28 PSM4 optical transceiver is engineered for medium-to-long-distance data center links. Key features include:

• Compliance: Fully compliant with the 100G PSM4 MSA specification.

• Protocol Support: Compatible with 100G Ethernet and InfiniBand EDR transport protocols.

• Technology: Employs four parallel single-mode fiber strands with a 1310nm central wavelength.

• Reach: Supports transmission distances of up to 2km or 10km, with Forward Error Correction (FEC) enabled for both ranges.



  P/N	Description
  VQM-SPO101-IR4C	100GbE QSFP28 Optical Transceiver, PSM4, DML 1310nm, 2km Reach
  VQM-SPO101-IR4T	100GbE QSFP28 Optical Transceiver, PSM4, DML 1310nm, 2km Reach, Industrial Grade
  VQM-SPO101-LR4C	100GbE QSFP28 Optical Transceiver, PSM4, DML 1310nm, 10km Reach
  VQM-SPO101-LR4T	100GbE QSFP28 Optical Transceiver, PSM4, DML 1310nm, 10km Reach, Industrial Grade

• Product Overview

  • Type: Pluggable Optical Transceiver Module

  • Form Factor: QSFP28




  Technical Specifications

  • Data Rate: 100G to 112G

  • Wavelength: 1310nm

  • Supported Protocols:

    • CPRI / eCPRI

    • Ethernet

    • InfiniBand

  • Media Type: Single-Mode Fiber (SMF)

  • Transmission Reach: 2 km to 20 km

  • Optical Interface: MPO/MTP Connector

    Applications

    • 5G Carrier Networks

    • Data Center Interconnects



Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders

BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
