100G QSFP28 LR1 Transceiver 1310nm 20km

The 100G QSFP28 LR1 optical transceiver module is designed for long-distance transmission in both datacom and telecom applications. It complies with the 100G Lambda MSA 100G LR1-10 and LR1-20 specifications and is compatible with the IEEE 802.3cu 100GBASE-LR1 Ethernet protocol.

This module operates over a pair of single-mode fibers with a central wavelength of 1310nm, supporting transmission distances of up to 10 km or 20 km when Forward Error Correction (FEC) is enabled.

Product Specifications: QSFP28 100G Optical Transceiver

• Product Type: Pluggable Optical Module

• Form Factor: QSFP28

• Data Rate: 100G

• Wavelength: 1310nm

• Media Type: Single-Mode Fiber (SMF)

• Interface / Connector: Dual LC

• Reach: 2km to 20km

• Supported Protocols:

  • Ethernet

  • Optical Transport Network (OTN)

• Applications:

  • 5G Carrier Network

  • Data Center Interconnects

  • Metropolitan Area Network (MAN)

  • Telecom Transport

Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders

BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
