The 100G QSFP28 ER4 optical transceiver module is designed for long-distance transmission in both data communication and telecommunications applications. It complies with the 100G Ethernet transmission protocol and is also compatible with the OTN OTU4 standard.
The module integrates an internal pair of 4-channel LWDM MUX and DEMUX, with center wavelengths set at 1295.56 nm, 1300.05 nm, 1304.58 nm, and 1309.14 nm. It supports transmission over a single-mode fiber pair, achieving distances of up to 30 km without Forward Error Correction (FEC) and up to 40 km with FEC.
| Part Number | Description |
|---|---|
| VQS-SPO101-ER4C | 100GE QSFP28 ER4 EML LWDM4 40km Optical Module |
| VQS-SPO111-ER4C | 100GE/OTU4 QSFP28 ER4 EML LWDM4 40km Optical Module |
Product Overview: QSFP28 100G ER4 Lite Optical Transceiver
This pluggable optical module is designed for high-performance, long-reach data transmission in demanding network environments.
Key Specifications:
Product Type: Pluggable Optical Module
Form Factor: QSFP28
Data Rate: 100G
Wavelength: LAN-WDM
Media Type: Single-Mode Fiber (SMF)
Reach: 25km - 50km
Interface: Dual LC
Supported Protocols: Ethernet, OTN (Optical Transport Network)
Applications:
5G Carrier Networks
Data Centers
Metropolitan Area Networks (MAN)
Telecom
